Archer MR400 AC1200 Wireless Dual Band 4G LTE Router

  • Cutting-edge 4G network – share internet access with up to 64 Wi-Fi devices and enjoy download speeds of up to 150 Mbps
  • AC1200 Wi-Fi – creates simultaneous dual band Wi-Fi networks, with maximum speeds of up to 300 Mbps on the 2.4 GHz band and 867 Mbps on the 5 GHz band
  • Plug a SIM card and play – no configurations needed, compatibility for SIM cards in 100+ countries are assured by years of field tests
  • Two detachable advanced LTE antennas – enjoy stable and efficient connections to every device thanks to the two external antennas
  • Wi-Fi router mode – plug an Ethernet cable into the LAN/WAN port for flexible access if you can’t get a 4G connection
View More

53,000.00

Product Description

*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage, and quantity of connected devices are not guaranteed and will vary as a result of network conditions, client limitations, and environmental factors, including building materials, obstacles, volume and density of traffic, and client location.

HARDWARE FEATURES
Interface 3× 10/100Mbps LAN Ports, 1× 10/100Mbps LAN/WAN Port, 1× Micro SIM Card Slot
Button WPS/RESET Button, Wi-Fi ON/OFF Button
External Power Supply 12V/1A
Dimensions ( W x D x H ) 6.85 × 4.9 × 1.32 in (174 × 124.5 × 33.5 mm)
Antenna 2× Detachable External 4G LTE Antennas
WIRELESS FEATURES
Wireless Standards IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz
Frequency 2.4 GHz and 5 GHz
Signal Rate 300Mbps at 2.4GHz, 867Mbps at 5GHz
Reception Sensitivity 5 GHz: 11a 54M: -77 dBm 11ac VHT20 MCS0: -95.5 dBm 11ac VHT20 MCS8: -73 dBm 11ac VHT40 MCS0: -93 dBm 11ac VHT20 MCS9: -68 dBm 11ac VHT80 MCS0: -90 dBm 11ac VHT20 MCS9: -65 dBm 2.4 GHz: 11g 54M: -74.5 dBm 11n HT20 MCS0: -92 dBm 11n HT20 MCS7: -73 dBm 11n HT40 MCS0: -89 dBm 11n HT40 MCS7: -70 dBm
Transmit Power < 20 dBm (2.4 GHz), < 23 dBm (5 GHz)
Wireless Functions Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics
WAN Failover Yes
Wireless Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions
Network Type 4G: FDD-LTE B1/B3/B7/B8/B20 (2100/1800/2600/900/800 MHz) TDD-LTE B38/B40/B41 (2600/2300/2500 MHz) 3G: DC-HSPA+/HSPA+/HSPA/UMTS B1/B8 (2100/900 MHz)
SOFTWARE FEATURES
Quality of Service Prioritizes network traffic by device or application
Operating Modes 3G/4G Router, Wireless Router
WAN Type Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)
Management Access Control, Local Management, Remote Management reboot schedule
DHCP Server, Client, DHCP Client List, Address Reservation
Port Forwarding Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS DynDns, NO-IP
VPN PPTP VPN, OpenVPN
Access Control Parental Control, Local Management Control
Firewall Security DoS, SPI Firewall, IP Address Filter/Domain Filter, IP and MAC Address Binding
Protocols Supports IPv4 and IPv6
Guest Network 2.4GHz guest network x 1, 5GHz guest network x 1
OTHERS
Certification CE, RoHS
Package Contents AC1200 Wireless Dual Band 4G LTE Router, Archer MR400 RJ45 Ethernet Cable Power Adapter Quick Installation Guide
System Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10 MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 browsers or higher, or other Java-enabled browsers Nano SIM Card
Environment Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing


There are no reviews yet.

Be the first to review “Archer MR400 AC1200 Wireless Dual Band 4G LTE Router”

Quick Comparison

SettingsArcher MR400 AC1200 Wireless Dual Band 4G LTE Router removeTP-Link TL-SF1008D 8-Port 10/100Mbps Switch removeEAP225 | AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point | TP-Link removeTP-Link 4G LTE Mobile WIFI - M7200 removeTP-Link TL-SG2428P | Jetstream 24 Port Gigabit Smart Managed PoE Switch | 24 PoE+ Ports removeTp-Link TL-CPE210 2.4ghz 300mbps remove
NameArcher MR400 AC1200 Wireless Dual Band 4G LTE Router removeTP-Link TL-SF1008D 8-Port 10/100Mbps Switch removeEAP225 | AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point | TP-Link removeTP-Link 4G LTE Mobile WIFI - M7200 removeTP-Link TL-SG2428P | Jetstream 24 Port Gigabit Smart Managed PoE Switch | 24 PoE+ Ports removeTp-Link TL-CPE210 2.4ghz 300mbps remove
SKU
Rating
Price 53,000.006,700.0028,000.00 35,000.0036,500.0030,000.00
Stock

5 in stock

Availability5 in stock
Add to cart
